4.5kA 6kA Miniature Circuit fifọ
Model:ALFHA
CDADA jẹ olupilẹṣẹ alamọdaju ti 4.5kA 6kA Miniature Circuit Breaker, ifọwọsi pẹlu CCC ati ISO9001 fun aabo iyika ailewu. O nlo ikarahun retardant ina ati didimu oofa-oofa deede, rọrun lati gbe sori iṣinipopada DIN ati rọrun lati ṣetọju. O darapọ iṣẹ iduroṣinṣin pẹlu igbesi aye iṣẹ pipẹ, apẹrẹ fun ibugbe, iṣowo ati pinpin agbara ile-iṣẹ.
CDADA ALFHA 4.5kA 6kA Miniature Circuit Breaker jẹ ẹrọ fifọ kekere ti o ga julọ, ti a funni nipasẹ ile-iṣẹ wa pẹlu awọn idiyele taara. O pese apọju ti o gbẹkẹle ati aabo Circuit kukuru fun awọn ọna ṣiṣe agbara foliteji kekere, pẹlu awọn iyipo tripping B / C / D lati baamu awọn ẹru oriṣiriṣi.
Ti a ṣe pẹlu ohun elo idaduro ina ati awọn paati konge, o ṣe idaniloju iṣẹ ailewu fun awọn ile, awọn ile-iṣelọpọ ati awọn igbimọ pinpin.
Awọn ẹya ara ẹrọ ọja & Awọn anfani
★ Ina-retardant, unflaming ikarahun, ga otutu sooro, egboogi-Yellowing
★ Ferese itọkasi wiwo: pupa fun ON, alawọ ewe fun PA fun ipo mimọ
★ Double rivets mu casing robustness fun ailewu onirin
★ Notched ebute clamps din ooru ati ki o mu asopọ iduroṣinṣin
★ Double titiipa DIN iṣinipopada agekuru fun sare, duro fifi sori
★ 90% awọn ẹya ti a ṣe ni ile fun didara iduroṣinṣin
★ 100% idanwo kikun ṣaaju gbigbe
Awọn ohun elo
CDADA 4.5kA 6kA Miniature Circuit Breaker jẹ lilo pupọ ni:
★ Ibugbe ile, Irini, Villas
★ Offices, tio malls, àkọsílẹ ohun elo
★ Awọn idanileko ile-iṣẹ, awọn panẹli pinpin agbara
★ Awọn onijakidijagan, awọn compressors, awọn ifasoke, awọn ọna gbigbe
★ Ina iyika ati kekere agbara ẹrọ
Imọ paramita
|
Nkan |
Sipesifikesonu |
|
Awoṣe |
ALFHA |
|
Standard |
IEC60898 |
|
Kikan Agbara |
4.5kA, 6kA |
|
Ti won won Lọwọlọwọ |
1A,2A,3A,4A,5A,6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
|
Awọn ọpá |
1P, 1P+N, 2P, 3P, 3P+N, 4P |
|
Tripping Curve |
B/C/D |
|
Ti won won Foliteji |
AC 230/400V, 400/415V |
|
Foliteji idabobo |
500V |
|
Impulse Foliteji |
4kV |
|
Idaabobo ìyí |
IP20 |
|
Fifi sori ẹrọ |
35mm DIN iṣinipopada |
|
Iwọn otutu ṣiṣẹ |
-5℃ ~ +40℃ |
|
Igbesi aye ẹrọ |
20.000 iyipo |
|
Itanna Life |
4,000 ~ 8,000 iyipo |
|
Awọn iwe-ẹri |
ISO9001, CCC, ASTA |
Awọn iwọn ila
★ Standard iwọn: 17.8mm fun polu
★ Dara fun 35mm DIN iṣinipopada iṣagbesori
★ iwapọ be fun boṣewa pinpin apoti
★ Agbara onirin: 1–35mm² rọ / okun lile
Iṣakoso didara
★ ISO9001 didara isakoso eto
★ 100% isọdiwọn ile-iṣẹ: 1.13Ni ti kii ṣe irin-ajo, 1.45Ni irin-ajo, 2.55Ninu idanwo
★ Oofa ati ki o gbona tripping ni kikun ijerisi
★ Ga ati kekere otutu ìfaradà igbeyewo
★ Isejade aifọwọyi ati alurinmorin konge
Iṣakojọpọ & Gbigbe
★ Standard okeere paali apoti
★ Kọọkan apoti ike pẹlu awoṣe, lọwọlọwọ, ọpá, opoiye
★ Shockproof akojọpọ ohun elo fun ailewu gbigbe
★ Dara fun okun, air ati ilẹ sowo
Awọn ọran Aṣeyọri Onibara
CDADA 4.5kA 6kA Miniature Circuit Breaker ti pese fun awọn alabara ni Yuroopu, Guusu ila oorun Asia, Aarin Ila-oorun, Afirika ati South America.
★ Awọn iṣẹ ile ibugbe ni UAE ati Saudi Arabia
★ Pipin agbara iṣowo ni Nigeria ati Angola
★ Industrial factory ẹrọ ni Germany ati Turkey
★ OEM ifowosowopo pẹlu agbaye itanna burandi
★ Ipese olopobobo igba pipẹ fun awọn olupin kaakiri ati awọn alagbaṣe
Gbona Tags: 4.5kA 6kA Miniature Circuit Breaker, China, Olupese, Olupese, Factory
