China Professional Distribution Box olupese

Ti o ba n wa lati ṣe akanṣe awọn apoti pinpin didara giga, ronu yiyanCDADA, a olupese orisun ni China. Ti iṣeto ni ọdun 2004-ati pẹlu awọn gbongbo wiwapa pada si awọn ọdun 1980-a ṣe ẹya awọn laini iṣelọpọ ni kikun ati pese awọn iṣẹ OEM iduro-ọkan. Ti o ba ni awọn ibeere eyikeyi nipa ohun elo itanna foliteji kekere, o le wa deede ohun ti o nilo pẹlu wa.

Kini Apoti Pinpin?

A apoti pinpin, tun mo bi aigbimọ pinpin, apejọ switchgear, tabi panelboard, jẹ apejọ ti a ti paade ti iyipada itanna ati awọn ẹrọ aabo ti a ṣe apẹrẹ lati gba agbara itanna lati orisun kan ati pinpin si awọn iyika pupọ. Ṣiṣẹ labẹIEC 61439 (idiwọn kariaye fun awọn ẹrọ iyipada foliteji kekere ati awọn apejọ jia iṣakoso), awọn apoti pinpin ṣiṣẹ bi aaye pataki fun iṣakoso agbara itanna ni ibugbe, iṣowo, ati awọn fifi sori ẹrọ ile-iṣẹ.

Awọn apoti pinpin wa lati kekereabele olumulo sipo (16-24 modulu) to tobiise agbara pinpin awọn ile-iṣẹ (titi di 6300A). Wọn ṣepọ awọn fifọ Circuit, awọn ẹrọ lọwọlọwọ lọwọlọwọ,awọn olubasọrọ, awọn ọkọ akero, ati ohun elo ibojuwo laarin apade aabo, ni idaniloju ailewu, igbẹkẹle, ati pinpin agbara ṣeto.

AwọnIEC 61439 boṣewa jara ṣe iyipada ile-iṣẹ naa nipa rirọpo jara IEC 60439 atijọ, ṣafihan awọn ibeere ijẹrisi apẹrẹ ti o han gbangba, awọn ilana ijẹrisi igbagbogbo, ati awọn igbese ailewu imudara lati daabobo eniyan ati ohun-ini.

Pinpin Box ọja Awọn ẹka & Awọn atunto

Iyasọtọ	Iru	Ibiti lọwọlọwọ	Awọn abuda bọtini
Nipasẹ Standard (IEC 61439)	IEC 61439-3 (DBO)	≤250A	Awọn igbimọ pinpin ti nṣiṣẹ nipasẹ awọn eniyan lasan, abele/ti owo, awọn iyika ti njade ≤125A
	IEC 61439-2 (PSC)	≤6300A	Awọn apejọ ẹrọ iyipada agbara, ile-iṣẹ, iṣẹ alamọdaju nikan
	IEC 61439-4 (ACS)	≤1000A	Awọn apejọ fun awọn aaye ikole, igba diẹ, gbigbe / alagbeka
	IEC 61439-5	≤2500A	Awọn nẹtiwọki pinpin kaakiri, awọn apoti ohun ọṣọ pinpin okun
	IEC 61439-7	O yatọ	Awọn ohun elo pato: marinas, gbigba agbara EV, awọn onigun ọja
Nipa Iṣagbesori	Odi-agesin	≤630A	Dada tabi danu iṣagbesori, IP30-IP65, ibugbe/ti owo
	Pakà-lawujọ	≤6300A	Freestanding, apọjuwọn ikole, ise/agbara awọn ile-iṣẹ
	Ọpá-agesin	≤400A	Ita gbangba pinpin, gbangba ina, igberiko electrification
Nipa Ikole	Irin paade	Gbogbo iwontun-wonsi	Irin / Aluminiomu, IP30-IP65, itanna shielding
	Awọn apade ti o ya sọtọ	≤250A	Thermoplastic (ABS, PC), IP40-IP65, ipata-sooro
	Awọn ọna ṣiṣe apọjuwọn	≤630A	DIN iṣinipopada iṣagbesori, 17.5mm modularity, rọ iṣeto ni
Nipa Ohun elo	Ibugbe	≤250A	Nikan-alakoso/mẹta-alakoso, MCB/RCD Integration, olumulo sipo
	Iṣowo	≤630A	Pinpin alakoso mẹta, awọn igbimọ ipin-pinpin, mita
	Ilé iṣẹ́	≤6300A	Awọn ile-iṣẹ iṣakoso mọto, pinpin agbara, iṣakoso ilana
	Amayederun	≤2500A	Awọn ohun elo, awọn ile-iṣẹ data, ilera, gbigbe

Awọn iwọn Diwọn (Awọn ọna ṣiṣe Apọjuwọn):

Ìbú: 370mm, 450mm, 620mm, 700mm, 900mm, 1000mm

Giga: 500mm to 2010mm

Ijinle: 267mm to 800mm (extensible to 1000mm)

Agbara module:10, 24, 36 modulu (17.5mm ipolowo)

Core Awọn iṣẹ & System Architecture

Awọn iṣẹ akọkọ

Išẹ	Apejuwe	Imọ imuse
Gbigba agbara	Gba agbara ti nwọle lati oniyipada, monomono, tabi pinpin oke	Oluyipada Circuit ti nwọle akọkọ (ICB), asopo-pada, tabi fiusi-yipada
Agbara pinpin	Pin agbara ti nwọle si awọn iyika ẹka lọpọlọpọ	Busbars (Ejò / aluminiomu), pinpin TTY, Circuit breakers
Circuit Idaabobo	Ṣe aabo lodi si awọn ẹru apọju, awọn iyika kukuru, ati awọn aṣiṣe aiye	MCBs, MCCBs, RCDs, RCBOs, fugear
Ìyàraẹniṣọ́tọ̀	Pese asopọ ailewu fun itọju	Yipada akọkọ, awọn asopo-pada pẹlu awọn olubasọrọ ti o han
Abojuto & Iṣakoso	Awọn wiwọn, diigi, ati idari awọn aye itanna	Awọn mita agbara, awọn atunnkanka didara agbara, ibojuwo latọna jijin, awọn fifọ ọlọgbọn
Didara Agbara	Idaabobo gbaradi, sisẹ ti irẹpọ, atunse ifosiwewe agbara	SPDs, ti nṣiṣe lọwọ Ajọ, kapasito bèbe

Busbar System Design

Awọn ọkọ akero fẹlẹhin ti awọn apoti pinpin, n ṣe awọn ṣiṣan giga laarin awọn iyika ti nwọle ati ti njade:

Paramita	Sipesifikesonu	Awọn Ilana Ohun elo
Ohun elo Busbar	Ejò ti o ni lile (C11000) tabi aluminiomu alloy (6101-T6)	ASTM B187, IEC 60428
Ti isiyi iwuwo	1.0-1.6 A/mm² (ejò), 0.8-1.2 A/mm² (aluminiomu)	Dide iwọn otutu ni opin si 65K (igboro), 80K (palara)
Diduro-Circuit Kukuru	10kA-100kA fun 1s (Icw)	IEC 61439-1, agbara ati ijẹrisi wahala gbona
dada Itoju	Tin plating (8-12μm) tabi fifi fadaka (3-5μm)	Idaabobo ipata, igbẹkẹle olubasọrọ
Atilẹyin Insulators	DMC (Agbo Molding Esufulawa) tabi SMC (Agbo Molding Sheet)	IEC 60168, atọka ipasẹ> 600V
Busbar iṣeto ni	3-alakoso + N + PE, tabi 3-alakoso + N (ya sọtọ)	Ilana ipele L1-L2-L3, didoju osi tabi ọtun julọ

Apeere Iwon Busbar:

2000kVA transformer, 400V, 3-alakoso

Kikun-fifuye lọwọlọwọ: 2887A

Aṣayan Busbar: 2× T2 bàbà ifi, 120mm × 10mm fun alakoso (2400mm²)

Iwọn iwuwo lọwọlọwọ: 1.2 A/mm²

Kukuru-Circuit withstand: 50kA/1s jẹri nipasẹ idanwo tabi iṣiro fun IEC/TR 60890

Ohun elo Ayika & Lo Awọn igba

Ohun elo	Eto Iru	Aṣoju Awọn pato	Awọn ibeere bọtini
Awọn ile ibugbe	Olumulo kuro, iyẹwu pinpin	≤250A, IP40, ogiri-agesin, 12-24 modulu, MCB+RCD	Aabo fun awọn eniyan lasan, ẹri-ifọwọyi, isamisi mimọ
Awọn ọfiisi Iṣowo	Iha-pinpin ọkọ, pakà pinpin	≤400A, IP30-IP54, odi/pakà, 36-72 modulu, mita	Ni irọrun fun awọn ayipada agbatọju, iwọn-mita, imugboroja iwaju
Ile Itaja	ayalegbe pinpin, akọkọ pinpin	≤630A, IP54, pakà-lawujọ, apọjuwọn, smart monitoring	Wiwa giga, iṣakoso fifuye, ibojuwo aarin
Awọn ile-iṣẹ data	Ẹka pinpin agbara (PDU), tẹ ni kia kia busway	≤1600A, IP20, pakà-lawujọ, 3N + PE, apọju	99.999% wiwa, gbona-swappable, latọna monitoring
Awọn ohun ọgbin ile-iṣẹ	Motor Iṣakoso aarin (MCC), agbara pinpin aarin	≤6300A, IP42-IP54, ilẹ-iduro, Fọọmu 4 Iyapa	Giga kukuru-Circuit withstand, motor Idaabobo, ilana Integration
Awọn ohun elo Ilera	Pinpin agbara pataki, agbara ti o ya sọtọ	≤800A, IP30, egbogi-ite, IT eto ibamu	Aabo alaisan, itesiwaju ipese, jijo lọwọlọwọ monitoring
Agbara isọdọtun	Apoti alapapo oorun, pinpin ibi ipamọ batiri	≤1500V DC, IP65, ita gbangba, ibojuwo okun	Idaabobo ẹbi DC arc, tiipa iyara, agbara ayika
Ikole Sites	Pinpin agbara igba diẹ, awọn agọ aaye	≤400A, IP44-IP65, transportable, logan ikole	Gbigbe, resistance oju ojo, ailewu fun lilo igba diẹ

Ilana iṣelọpọ & Ṣiṣẹda Ṣiṣẹjade

Konge Manufacturing ọkọọkan

Ohun elo Raw IQC → Iṣe-iṣẹ Irin Sheet → Itọju Ilẹ → Ṣiṣeto Busbar → Isopọpọ paati → Wiring & Apejọ → Idanwo & Imudaniloju → Ik QC → Iṣakojọpọ & Ifijiṣẹ

Lominu ni Awọn ipele iṣelọpọ

Ipele	Awọn alaye ilana	Awọn aaye Iṣakoso Didara
Dì Irin iṣelọpọ	Irin ti a yiyi tutu (CRCA) tabi iwe aluminiomu, gige laser, lilu CNC, atunse, alurinmorin	Ifarada iwọn ± 0.5mm, awọn egbegbe ti ko ni burr, ilaluja weld, fifẹ <1mm/m
dada Itoju	Ilọkuro, phosphating, ohun elo elekitirositatic lulú (epoxy-polyester), imularada (180-200°C/20min)	Iwọn ibora 60-80μm, idanwo gige-agbelebu 0-1, sokiri iyọ 500-1000h
Ṣiṣeto Busbar	Ige, punching, atunse, Tin/ti fadaka, sleeving idabobo	Iṣe adaṣe ≥100% IACS (Ejò), sisanra dida 8-12μm, ko si awọn burrs, iyipo eti
Iṣagbesori paati	DIN iṣinipopada fifi sori, Circuit fifọ iṣagbesori, busbar asopọ, iyipo-dari tightening	Torque fun pato olupese (1.5-5.0Nm), titete, kiliaransi / ijẹrisi oju-iwe
Ti abẹnu Wiring	Awọn kebulu Ejò (H05RR-F, H07RN-F), ifopinsi ferrule, ifaminsi awọ (L1-brown, L2-dudu, L3-grẹy, N-buluu, PE-alawọ ewe/ofeefee)	Idanwo itesiwaju, idabobo idabobo> 1MΩ, ipasẹ to tọ
Ijerisi Apejọ	Isẹ ẹrọ, titiipa ilẹkun, lilẹ, isamisi, iwe	Ayẹwo iṣẹ-ṣiṣe 100%, ijẹrisi IP, ibamu pẹlu IEC 61439-1
Idanwo & Ijeri	Idanwo Dielectric (2kV/1min), idabobo idabobo, ilosiwaju, polarity, lẹsẹsẹ alakoso	Ijẹrisi igbagbogbo fun IEC 61439-1, iran ijabọ idanwo
Ipari Ayẹwo	Ayewo wiwo, ayẹwo onisẹpo, atunyẹwo iwe, ijẹrisi isamisi	Ikede ti ibamu, faili imọ-ẹrọ, ilana fifi sori ẹrọ

Awọn ohun elo Raw akọkọ & Awọn pato paati

Ẹya ara ẹrọ	Ohun elo Specification	Awọn ajohunše olupese	Awọn ohun-ini bọtini
Apade Ara	Tutu-yiyi irin SPCC (1.0-2.0mm) tabi aluminiomu 5052-H32 (1.5-3.0mm)	JIS G 3141, ASTM B209	Agbara ikore ≥180MPa, agbara oofa (irin), resistance ipata (Al)
Aso lulú	Epoxy-polyester arabara, RAL 7035 (ina grẹy) tabi RAL 7032 (pebble grẹy)	ISO 12944, Qualicoat	Sisanra 60-80μm, didan 60-80%, resistance resistance> 50cm · kg
Awọn ọkọ akero	Electrolytic Ejò T2 (Cu-ETP, ≥99.9%) tabi aluminiomu 6101-T6	ASTM B187, IEC 60428	Iṣeṣe ≥100% IACS (Cu), ≥55% IACS (Al), líle HV 80-120
Awọn atilẹyin Busbar	DMC (Agbo Molding Esufulawa) tabi SMC (Agbo Molding Sheet)	IEC 60168, UL 94 V-0	Atọka ipasẹ> 600V, resistance ooru 180 ° C, agbara rọ> 150MPa
DIN Rail	Irin (sinkii-palara) tabi aluminiomu (anodized), TH35 (35mm × 7.5mm)	IEC 60715, EN 50022	Titọ <0.5mm/m, agbara fifuye> 100N, idena ipata
Awọn edidi ilekun	EPDM roba tabi polyurethane foomu, gasiketi profaili	ASTM D2000, UL 50	Iwọn iwọn otutu -40°C si +120°C, tito funmorawon <25%, IP65 lilẹ
Mita & Awọn titipa	Zinc alloy (ZDC) tabi irin alagbara, irin 304, chrome-palara	ASTM B86, ISO 9227	Sokiri iyọ 240-500h, igbesi aye ọmọ> awọn iṣẹ ṣiṣe 10,000, resistance tamper
Awọn keekeke USB	Polyamide (PA66) tabi nickel-palara idẹ, IP68	IEC 62444, UL 514B	Iwọn otutu -40 ° C si + 100 ° C, iderun igara, aṣayan idaabobo EMC
Awọn ohun elo idabobo	PET (Mylar), PVC, tabi nomex fun idabobo bosibar	IEC 60216, UL 94 V-0	Agbara dielectric>15kV/mm, atọka iwọn otutu>130°C

Ibamu Awọn ajohunše & Awọn Ilana Idanwo

International Standards Framework

Standard	Ààlà	Awọn ibeere to wulo
IEC 61439-1: 2020	Awọn ofin gbogbogbo fun kekere-foliteji switchgear ati awọn apejọ iṣakoso	Boṣewa ipilẹ, ijẹrisi apẹrẹ, ijẹrisi igbagbogbo, igbega iwọn otutu, duro-kukuru
IEC 61439-3: 2024	Awọn igbimọ pinpin ti nṣiṣẹ nipasẹ awọn eniyan lasan (DBO)	Abele / ti owo, ≤250A, ≤300V si aiye, ailewu fun ti kii-ọjọgbọn
IEC 61439-2: 2011	Agbara switchgear ati awọn apejọ iṣakoso	Iṣẹ-iṣẹ, lilo alamọdaju nikan, to 6300A
IEC 61439-4: 2023	Awọn apejọ fun awọn aaye ikole (ACS)	Awọn fifi sori igba diẹ, gbigbe, ikole ti o lagbara
IEC 61439-6: 2012	Awọn ọna ṣiṣe gọọsi (awọn ọna opopona)	Pinpin agbara nipasẹ awọn busbars, awọn ifilelẹ ti nyara, awọn ẹya titẹ ni kia kia
IEC 61439-7: 2014	Awọn ohun elo kan pato (marinas, gbigba agbara EV, ati bẹbẹ lọ)	Awọn agbegbe pataki, awọn ibeere aabo afikun
IEC 62208:2011	Awọn apade ti o ṣofo fun awọn apejọ ẹrọ iyipada foliteji kekere	Iṣẹ iṣẹ-iṣiro, aabo ayika, agbara ẹrọ
IEC/TR 60890:2014	Ijerisi iwọn otutu-jinde nipasẹ iṣiro	Yiyan si igbeyewo, gbona modeli
IEC / TR 61439-0: 2013	Itọsọna si pato awọn apejọ	Olumulo sipesifikesonu, ni wiwo paramita

Ijẹrisi dandan (IEC 61439-1)

Ijerisi Iru	Idanwo / Iṣiro	Awọn Ilana gbigba
Ijeri Oniru (Iru Idanwo)	Awọn ifilelẹ lọ iwọn otutu	Awọn ibudo ≤80K (palara), ≤65K (igboro); Apade ≤40K; Busbars fun ohun elo
	Kukuru-Circuit duro agbara	Icw fun 1s, Ipk tente oke lọwọlọwọ, ko si abuku, ko si eewu, iṣẹ lẹhin idanwo
	Dielectric-ini	2kV-3.5kV / 1min igbohunsafẹfẹ agbara, ko si didenukole, ko si flashover
	Awọn imukuro ati awọn ijinna irako	Fun alefa idoti, agbara ti o ni iwọn pẹlu agbara foliteji
	Isẹ ẹrọ	Awọn iṣẹ ṣiṣe 200-1000, ko si yiya pupọ, awọn ibeere agbara
	Iwọn aabo (IP)	Ijẹrisi koodu IP (eruku, omi), IEC 60529
	Resistance si ipata	Sokiri iyọ, ọriniinitutu, ko si ibajẹ ti o ni ipa lori ailewu
Ìmúdájú ìgbà gbogbo (Gbogbo Ẹ̀ka)	Atunse onirin, iṣẹ ṣiṣe	Itesiwaju, polarity, phasing, darí iṣẹ
	Dielectric igbeyewo	1kV-2kV/1s tabi 2U + 1000V, ko si didenukole
	Idaabobo idabobo	≥1000Ω/V ni 500V DC
	Awọn ọna aabo, itesiwaju itanna	≤0.05Ω laarin awọn ẹya idari ti o han ati ebute PE

Iṣakoso Didara Factory & Awọn ajohunše Ayewo

Ohun elo ti nwọle QC (IQC)

Ohun elo	Awọn nkan Ayẹwo	Iṣapẹẹrẹ Eto	Ohun elo
Irin sheets	Sisanra, ikore agbara, dada didara, adhesion ti a bo	Fun ipele, COA + idanwo	Idanwo fifẹ, iwọn sisanra ti a bo, idanwo tẹ
Aluminiomu sheets	Alloy ite, sisanra, anodizing didara	Fun ipele	Spectrometer, micrometer, anodizing sisanra ndan
Ejò akero	Ti nw, ifọnọhan, lile, ifarada onisẹpo	Fun ipele	Mita iṣiṣẹ, oluyẹwo lile, CMM
Ti a bo lulú	Awọ baramu, didan, arowoto ìyí, sisanra	Fun ipele	Mita didan, mita imularada, iwọn sisanra, spectrophotometer awọ
Ṣiṣu irinše	Flammability (UL 94), atọka ipasẹ, iduroṣinṣin onisẹpo	Fun ipele	Ohun elo idanwo UL 94, idanwo ipasẹ, idanwo ipalọlọ ooru

Iṣakoso Didara Ninu Ilana (IPQC)

Ibudo	Iṣakoso paramita	Igbohunsafẹfẹ	Ọna
Lesa gige / punching	Iwọn deede ± 0.2mm, didara eti, iga burr	Ni gbogbo ọgbọn iṣẹju	CMM, wiwo wiwo, micrometer
Titẹ	Idede igun ± 0.5 °, rediosi tẹ, fifọ dada	Gbogbo setup + apẹẹrẹ	Iwọn igun, iwọn radius, ayewo wiwo
Alurinmorin	Ilaluja, irisi ilẹkẹ, iṣakoso ipalọlọ	Gbogbo weld ipele	Ayewo ojuran, ti nwọle awọ, X-ray (pataki)
Ti a bo lulú	Fiimu sisanra 60-80μm, iṣeto imularada, aitasera awọ	Gbogbo ipele	Iwọn sisanra, mita imularada, afiwe awọ
Busbar processing	Gige ipari, apẹrẹ iho, sisanra fifin, iyipo eti	Gbogbo nkan	CMM, sisanra fifin XRF, ayewo wiwo
Apejọ	Yiyi iṣagbesori paati, titete, awọn ijinna imukuro	Gbogbo kuro	Torque wrench, awọn bulọọki iwọn, ayewo wiwo

Iṣakoso Didara Ipari (FQC) & QC ti njade (OQC)

Nkan Idanwo	Standard	Apeere Iwon
Ijẹrisi iwọn	Awọn iwọn apapọ, titete ilẹkun, awọn ihò iṣagbesori	100%
IP Rating ijerisi	Iduroṣinṣin edidi, funmorawon gasiketi, ilẹkun ilẹkun	AQL 1.0 (apẹẹrẹ)
Dielectric withstand igbeyewo	2kV AC/1min (awọn iyika akọkọ), 1kV AC/1min (oluranlọwọ)	100%
Idaabobo idabobo	≥1MΩ @ 500V DC	100%
Ilọsiwaju ti awọn iyika aabo	≤0.05Ω laarin PE ojuami	100%
Polarity ati ijerisi alakoso	Atunse ni gbogbo awọn ebute	100%
Isẹ ẹrọ	Ilekun, awọn titiipa, awọn mitari, awọn ẹya yiyọ kuro	100%
Ayẹwo wiwo	Awọn abawọn ibora, isamisi, mimọ	100%
Atunwo iwe	Awọn aworan onirin, awọn ijabọ idanwo, ikede ibamu	100%
Iṣootọ iṣakojọpọ	Idaabobo lakoko gbigbe, awọn ilana mimu	Fun Pupo

Awọn amayederun iṣelọpọ & Agbara iṣelọpọ

To ti ni ilọsiwaju Production Equipment

Ẹka ẹrọ	Machine Specification	Išẹ	Agbara
dì Irin Processing	CNC lesa gige	Ige konge, eka profaili, Burr-free egbegbe	10 tonnu / ọjọ
	CNC punching	Iho ilana, louvers, embossing	5,000 paneli / ọjọ
	CNC titẹ idaduro	Yiyi konge, awọn geometries eka	2,000 enclosures / ọjọ
dada Itoju	Aládàáṣiṣẹ lulú ti a bo ila	Pretreatment, powder elo, curing	5,000 m² fun ọjọ kan
Ṣiṣeto Busbar	CNC busbar punching / atunse ẹrọ	Ige, punching, atunse, plating	2.000 busbar tosaaju / ọjọ
Apejọ Lines	Awọn ibudo apejọ apọjuwọn, aabo ESD, ibojuwo iyipo	Iṣagbesori paati, onirin, idanwo	1,000 pinpin apoti / ọjọ
Ohun elo Idanwo	Ibujoko idanwo adaṣe (dielectric, idabobo, itesiwaju)	Ijẹrisi igbagbogbo fun IEC 61439	500 sipo / ọjọ
Ohun elo Idanwo	Iṣeto idanwo iwọn otutu (abẹrẹ lọwọlọwọ to 6300A)	Ijẹrisi oniru, iru idanwo	10 setups / osù

Agbara iṣelọpọ & Awọn akoko asiwaju

Ẹka ọja	Oṣooṣu Agbara	Standard asiwaju Time	Agbara Bere fun kiakia
DBO ibugbe (≤250A, ti a gbe ogiri)	50.000 sipo	4-5 ọsẹ	3 ọjọ
Pipin iṣowo (≤630A, pakà/odi)	20.000 sipo	4-5 ọsẹ	5 ọjọ
Awọn ile-iṣẹ agbara ile-iṣẹ (≤2500A, ti o duro lori ilẹ)	5.000 sipo	4-5 ọsẹ	7 ọjọ
Awọn ojutu ti a ṣe atunṣe aṣa (≤6300A)	Ipilẹ ise agbese	4-8 ọsẹ	2-3 ọsẹ
Modulu busbar awọn ọna šiše	10.000 mita	4-5 ọsẹ	5 ọjọ

Engineering & Technical Team Be

Ẹka	Eniyan	Amoye	Awọn ojuse
R&D Imọ-ẹrọ	5 awọn ẹlẹrọ	IEC 61439 ibamu, awoṣe gbona, iṣiro kukuru kukuru, imọ-jinlẹ ohun elo	Idagbasoke ọja titun, iṣapeye apẹrẹ, portfolio itọsi (awọn itọsi 40+)
Imọ-ẹrọ ilana	25 Enginners	Ṣiṣẹda irin dì, itọju dada, sisẹ busbar, iṣelọpọ titẹ si apakan	Imudara iṣelọpọ, adaṣe, ilọsiwaju ikore (> 98%), idinku idiyele
Idanwo & Afọwọsi	20 Enginners	IEC 61439 ijerisi, idanwo jinde iwọn otutu, idanwo kukuru kukuru, EMC	Iru iṣakojọpọ idanwo, iṣeduro igbagbogbo, itupalẹ ikuna, iwe-ẹri
Ohun elo Engineering	15 Enginners	Apẹrẹ eto agbara, isọdọkan yiyan, abojuto fifi sori ẹrọ, fifisilẹ	Atilẹyin imọ-ẹrọ alabara, apẹrẹ ero, abojuto aaye, ikẹkọ
Didara ìdánilójú	35 onimọ	ISO 9001, ISO 14001, iṣakoso ilana iṣiro, yàrá metrology	Ayẹwo olupese, iṣayẹwo ilana, iṣe atunṣe, iṣakoso isọdọtun

Kini idi ti Ṣiṣe Apoti Pinpin Wa Duro Yato si

Ile-iṣẹ iṣelọpọ wa ṣe aṣoju25 ọdun ti pataki ni awọn apejọ kekere-foliteji switchgear, jiṣẹ awọn apoti pinpin ti o kọja awọn iṣedede agbaye nipasẹ:

IEC 61439 ĭrìrĭAwọn agbara ijẹrisi apẹrẹ okeerẹ pẹlu iṣiro iwọn otutu fun IEC / TR 60890 ati idaniloju idaniloju kukuru kukuru fun Annex P ti IEC 61439-1

Inaro Integration: Ṣiṣẹpọ irin dì inu ile (gige lesa, punching, atunse), itọju dada (aṣọ lulú adaṣe), ati ṣiṣe busbar ni idaniloju iṣakoso didara pipe.

Idanwo amayederun:$ 5M + ṣe idoko-owo ni iru ohun elo idanwo pẹlu awọn iṣeto idanwo iwọn otutu (abẹrẹ lọwọlọwọ 6300A), awọn ohun elo idanwo kukuru, ati awọn iyẹwu ayika

Irọrun modulu:Awọn apẹrẹ pẹpẹ ti o ni idiwọn ti n mu isọdi iyara ṣiṣẹ lakoko mimu ibamu IEC 61439 ati ṣiṣe idiyele

Imọye ohun elo:Awọn solusan pataki fun awọn ile-iṣẹ data (Iyapa Fọọmu 4), ilera (awọn eto IT), agbara isọdọtun (pinpin DC), ati awọn agbegbe lile (IP65, Tropicalized)

CDADA jẹ Apoti pinpin olupese ati olupese ni Ilu China. Ile-iṣẹ wa n ṣe iranṣẹ awọn ile-iṣẹ Oniruuru gẹgẹbi awọn eto agbara, adaṣe ile, ati iṣelọpọ ile-iṣẹ, ti nfunni ni irọrun OEM / ODM awọn solusan.
